Salt Spray Chamber

Name: Salt Spray Chamber
Brand: GLOBAL CORPORATION

Get a Price/Quote

MOQ : 1 Unit

Salt Spray Chamber Specification

Port Size
1/4 inch

Equipment Type
Corrosion Testing Chamber

Response Time
Instantaneous thermal response

Frequency
50 Hz

Display Type
Digital/LED

Max Height
1080 mm

Specimen Size
Up to 150 70 mm

Number of Specimens
Up to 40 pieces

Temperature
35C 1C (Salt Spray); 50C 1C (Condensation)

Test Range
Continuous or cyclic salt spray tests

Resolution
0.1C

Power Supply
220V AC / 50Hz

Accuracy
0.1C

Application
Corrosion resistance testing of coatings, metals, and surface treatments

Operating Voltage
220V AC

Usage
Salt spray (fog) corrosion test

Capacity
108 liters

Machine Weight
125 kg

Test Speed
Adjustable

Test Width
500 mm

Test Stroke
400 mm

Control Mode
Digital/Manual

Salt Spray Chamber Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Against Delivery (CAD), Cash in Advance (CID), Cheque, Cash Advance (CA)

Supply Ability
Unit

Delivery Time
1 Months

Packaging Details
Paid Packaging

Main Export Market(s)
Australia, Eastern Europe, North America, Western Europe, Africa, Central America, Middle East, South America, Asia

Main Domestic Market
All India

About Salt Spray Chamber

Owing to our transparent business policies, we are trusted all over the world as a manufacturer, supplier and exporter of Salt Spray Chamber. We are supplied with superior grade material and other components that are used in the manufacturing process to obtain the finished product in compliance with the predefined quality standards. It determines the resistance against corrosion of protective lacquer coating, which is applied on ferrous and non ferrous materials. The Salt Spray Chamber is well acclaimed in the global market for the following features:

Low maintenance
User-friendly
Power efficient
Longer functional life

Additional information:

The Global Corporation Salt spray Corrosion Cabinet is used to test the corrosion resistance of protective lacquer coating on ferrous &non ferrous material.

Made of perfect inert material (Acrylic) . The Chamber will be MONO- BLOCK construction that comprises all systems necessary for operation.
* Test Space: Made up of FRP/PP non-corrosive material.
* Insulation: The insulation material will be of low k factor, high density
& non hygroscopic nature of mineral fiber.
* Door: will be made-up of non-corrosive Acrylic with hinges in the REAR. The door will be having inclined ceiling provided with side wall baffles to avoid droplets falling on to specimen.
* Air Regulator: Moisture & Oil Filter cum Regulator ranging from 0-30 psi is incorporated with the UNIT.
* The Chamber has a gabble type cover.
* Atomizer: Non-corrosive trouble free Atomizer capable of producing a fine FOG of 20-30 micromoles size is installed with UNIT.
* Saturator: A temp controlled non-corrosive saturator with built-in AUDIO VISUAL automatic waterlevel watch-dog solid state electronic buzzer Alarm circuit & immersion heater is provided with UNIT.
* Specimen Placement: FRP Acrylic blocks will be provided for hanging the specimen.
* Heating of Test Space: The heating of the chamber will be done by using tape Heater of suitable capacity & mounted to have uniform heating.
* Instrumentation & Control: the Chamber will be provided with PID Auto tuned Microprocessor based dual Display (For SET / Present value of temp) Temperature Indicator cum Controller, Safety Standby Thermostat Timer, Water Level AUDIO VISUAL Watch dog Solid state electronic circuit for Heater cut-off & safety, PT-100 sensor with non-corrosive Glass is incorporated with UNIT.
Suitable for panels of size 150mm x 100mm x 1.25mm

*The panel will be placed at an angle of 15 on Acrylic

The panels are equally placed at a distance of 20mm from each other as well from the walls.

*SIZES: A) 680L x 420W x 410H mm for 24 Panels/16 Panels;
(Chamber of 6mm Thick Acrylic)

*The chamber has gable type cover.

Temp Range: Ambient to 50*C, Humidity Range: 95% to 98% will be provided during salt spray depending upon saturation of salt solutions.

Temp Control Accuracy: Better then +/-1*C

B) For Chamber Size: 950(L) X 750(W) X 650(H)mm
(Chamber of 8mm thick Acrylic)

ACCESSORIES: Sample hanger & Tray, Air purging system.

Optional: On demand Software based Microprocessor programmable PID controller with Time proportionate bands, data logger & cyclic timer, real clock battery backup, RAM memory, printer & PC interface controller with PT-100 sensor can be provided with the unit at Extra cost. Our technology is fully controlled, easy to handle, user friendly, intelligent and reliable.

Precision and Efficiency in Corrosion Testing

Engineered for laboratories and industrial quality control, this Salt Spray Chamber enables highly controlled tests with adjustable spray rates and temperature stability. The digital interface, combined with manual controls, offers exceptional flexibility in managing various corrosion protocols, making it suitable for comprehensive research and development needs.

Durable Construction for Reliable Performance

Featuring a high-grade FRP inner chamber and powder-coated mild steel exterior, the chamber ensures superior resistance to corrosive environments and long-term structural integrity. This thoughtful design minimizes maintenance requirements, providing uninterrupted operation for extended testing schedules.

Comprehensive Safety and User-Friendly Operation

The chamber integrates safety mechanisms like water shortage protection, overheat prevention, and a leakage breaker for operator assurance. The intuitive LED/digital display grants real-time monitoring, while the integrated, adjustable air regulator simplifies spray control for precise testing outcomes.

FAQs of Salt Spray Chamber:

Q: How does the Salt Spray Chamber operate during a corrosion test?

A: The chamber utilizes a precision atomizer nozzle to evenly distribute a salt-laden mist onto test specimens at specified rates. By maintaining precise temperatures and humidity within the chamber, it simulates harsh corrosive conditions. Tests can be continuous or cyclic, depending on the application requirements.

Q: What types of specimens can be tested and in what quantities?

A: Up to 40 specimens can be tested simultaneously, provided their dimensions do not exceed 150 70 mm each. This capacity makes the chamber suitable for evaluating a variety of coatings, metals, and surface treatments.

Q: When should the Salt Spray Chamber be used in a manufacturing process?

A: This chamber is ideal for use during quality control stages, product development, or comparative performance analyses. It helps manufacturers ensure that protective coatings and treatments meet specified corrosion resistance standards before products are released.

Q: Where is this Salt Spray Chamber typically installed?

A: Owing to its manageable dimensions and robust build, the chamber is generally installed in research laboratories, manufacturing quality control units, or testing facilities equipped with a 220V AC power supply.

Q: What is the process for setting up and running a test in this chamber?

A: Users place the specimens inside the chamber, fill the solution reservoir, set the desired test parameters via digital or manual controls, and initiate the test. Built-in safety features and the digital display provide real-time monitoring throughout the test cycle.

Q: What are the benefits of using a Salt Spray Chamber with high-grade FRP and powder-coated MS sheet construction?

A: The combination of high-grade FRP for the inner chamber and powder-coated MS for the outer structure ensures excellent resistance to corrosive agents, enhancing the equipments longevity and providing robust performance even with frequent, prolonged use.
