Drum Heater

About Drum Heater

GMP-GC-42 Drum Heater

Construction: This Industrial drum heater (for MS DRUM ,vertical model) has a well type, triple walled construction. The Innermost chamber is made of MS perforated Sheet with a heat resistive silver paint finish, the middle chamber MS has an insulated compartment and the outer chamber is also made of MS with a powder coat finish. The unit has an electrical heating system, suitable for heating 200ltrs standard size drum. The drum heater is made into 2 semicircular halves, which are joined at one end by heavy duty hinges & clamps at the other end by a special press fit adjustable lock, with the control panel on one half with  heater,& heater + connector junction box on the other half in the innermost compartment. The outermost compartment is filled-up with high density glass wool insulation of 65mm to have skin temperature of Drum less than 45*C. SS U finned type heaters of suitable capacity clamped with inner surface with HOT + COLD Zone junction(with lead-wire taken out of Drum at base with safety cover for ease of checking/servicing) is used as the heating element for uniform distribution of heat. The maximum achievable temp. is 150C. An Imported Capillary type Thermostat is provided for setting required SET temp to control with Contactor/Heavy duty Relay. Digital microprocessor PID temperature controller cum indicator with Fe-con Thermocouple sensor controls the heating process as Option. The unit is easily moveable on its castor wheels.

Power: 440 V, 50 Hz, 3- power supply.

NEW  LOW  COST  DRUM  HEATER   (Encapsulate Type Band Heater) :
(For Plastic /FRP DRUM Body)





Drum Heaters

A simple , effective and reliable way to heat the contents of your drums. A drum heater is available for almost any steel, plastic or fibre drum. .Even  heaters for metal and plastic 5-gallon pails.

         Steel pail 4 KWatt (2Kwatt in each Half circle of RIB) with 6" wide band HEATER per RIB with Thermostat Control individually for each Half RIB, Operate on 230V,50 Hz for 210LTR Capacity MS DRUM. (NOTE: There are 3 no of RIB in MS DRUM)
Temperature Control Range: 50*C to 250*C

         Plastic pail - 600 watt (300 watt in each Half circle of RIB) with 3" wide band Drum heater
per RIB with Thermostat Control individually for each Half RIB, Operate on 230V,50 Hz for 210LTR Capacity Plastic DRUM. (NOTE: There are 3 no of Heater in Plastic DRUM)
Temperature Control Range: Ambient  to 50*C maximum

Applications

         Maintain liquid temperatures in water purification systems

         Keep resin at optimum temperature

         Control viscosity of chemical binder in sand casting mould operation

         Protect materials vulnerable to freeze damage Adhesives/Asphalt/tar/creosote Brine Chemicals/ Chocolate /Corn syrup /Vegetable oils/ Wax et



For GLOBAL CORPORATION

Optimal Heating for Industrial Drums

Engineered for consistent and efficient warming, the drum heater keeps viscous fluids at just the right temperature for processing or handling. Its a preferred solution for chemical, food, and pharmaceutical applications, ensuring better fluidity and preventing material solidification. Operating on 220V AC, its flexible silicone sleeve guarantees a snug fit and efficient heat distribution, safeguarding productivity and quality.


Flexible and Safe in Performance

With a focus on usability and safety, the IP65-rated enclosure offers excellent waterproofing and protection against dust. Overheat protection mechanisms and adjustable thermostats assure controlled operations, while simple installation and removal enable convenient day-to-day use. Custom cable lengths and drum sizes allow for versatile adaptation, meeting diverse industrial requirements with ease.
